OpenEVSE and Home Assistant Fordpass range integration is off

[chriserx]

Anyone using this or maybe a similar setup and notice that the range is off by 1.61x. It's obviously a miles to kilometers conversion problem. I've tried different settings in different locations, outside of looking at the code for Home Assistant and HA Fordpass, anyone have a fix I may be overlooking? The only thing I know I haven't tried is changing the Ford app to report km. Range shows right everywhere but in the OpenEVSE entity for Home Assistant. Pretty minor but kinda annoying.

Sponsored



[chriserx]

I realize this isn't going to be a super popular setup, I made several automations by myself to control to taper the charge rate without setting a hard cut off limit like most setups for HVB battery life and to support the LVB without a battery maintainer. Then I consulted ChatGPT about it not realizing that I could combine all of the automations into one so I thought I'd share in case anyone else's charger is compatible with Home Assistant, which may require modification.

Prerequisites as is:
OpenEVSE
Home Assistant with HA Fordpass
Home Assistant Helper Toggle labled Full Charge Mode

Variables to replace:
OpenEVSE_device_id
OpenEVSE_entity_id
VIN
--------------------------
alias: OpenEVSE 4-Stage Charge Curve with Cold-Weather Support

entity_id: sensor.openevse_evse_vehicle_state_of_charge
below: 53
sequence:
- device_id: OpenEVSE_device_id
domain: number
entity_id: OpenEVSE_entity_id
type: set_value
value: 48
- conditions:
- condition: numeric_state
entity_id: sensor.openevse_evse_vehicle_state_of_charge
above: 52
below: 66
sequence:
- device_id: OpenEVSE_device_id
domain: number
entity_id: OpenEVSE_entity_id
type: set_value
value: 32
- conditions:
- condition: numeric_state
entity_id: sensor.openevse_evse_vehicle_state_of_charge
above: 65
below: 76
sequence:
- choose:
- conditions:
- condition: numeric_state
entity_id: sensor.fordpass_VIN_outsidetemp
below: 40
sequence:
- device_id: OpenEVSE_device_id
domain: number
entity_id: OpenEVSE_entity_id
type: set_value
value: 20
default:
- device_id: OpenEVSE_device_id
domain: number
entity_id: OpenEVSE_entity_id
type: set_value
value: 16
- conditions:
- condition: numeric_state
entity_id: sensor.openevse_evse_vehicle_state_of_charge
above: 74
sequence:
- choose:
- conditions:
- condition: numeric_state
entity_id: sensor.fordpass_VIN_outsidetemp
below: 40
sequence:
- device_id: OpenEVSE_device_id
domain: number
entity_id: OpenEVSE_entity_id
type: set_value
value: 16
default:
- device_id: OpenEVSE_device_id
domain: number
entity_id: OpenEVSE_entity_id
type: set_value
value: 6
mode: single
--------------------------
Profile has hysteresis but is generally:
0-50% 48A
51-65% 32A
66-75% 16A, below 40F 20A
75-100% 6A, below 40F 16A
